LSIS eXP Series, eXP20-TTA User Manual

Chapter 4 System Configuration
4-11
4.5 Ethernet Setting
If you press [Ethernet Setting] button in [System Configuration] screen as follows, you can change IP to use
Ethernet.
[XGT Panel Setting]
You can change IP address by pressing [Set] button of each IP address, Subnet Mask and Gateway. By
pressing OK button, changed IP information is reserved.
Remark
We recommend the following method, when connecting with PC solely.
If you reboot after pressing [Disable] button, the device will not use Ethernet. In this case, booting speed gets
faster.
If you use Ethernet again, reboot after pressing [Enable].
1) XGT Panel setting
- IP Address : 192.168.0.10
- Subnet Mask: 255.255.255.0
- Gateway : 192.168.0.1
2) PC setting
- IP Address : 192.168.0.11
- Subnet Mask: 255.255.255.0
- Gateway : 192.168.0.1
