Chapter 3 Standard Specification
3-1
Chapter 3 Standard Specification
3.1 General Standards
XGT Panel general standard is as follows.
No.
Category
Standard
Related standard
1
Ambient operating
temperature
0℃∼+50℃
-
2 Storage temperature
-20℃∼+60℃
-
3
Operating humidity
10
∼
85%RH, non-condensing.
-
4 Storage humidity
10∼85%RH, non-condensing.
-
5 Vibration resistance
Occasional vibration
count
-
Frequency Acceleration Amplitude
10 times each in X, Y
and Z direction
IEC 61131-2
5≤f< Hz
-
3.5 mm
9≤f≤150 Hz 9.8 m/s
2
-
Continuous vibration
Frequency
Acceleration
Amplitude
5≤f< 9 Hz - 1.75 mm
9≤f≤150 Hz
4.9 m/s
2
-
6 Shock endurance
* Maximum shock acceleration: 147 m/s
2
(15G)
* Duration time: 11 ms
* Pulse wave: half sine pulse (3 times each in X, Y and Z directions)
IEC 61131-2
7
Noise
Immunity
Square wave
Impulse noise
DC: ±1,200V LSIS Standard
Electrostatic Discharge
Immunity
±6 kV(Contact Discharge),
±8 kV(Air Discharge)
IEC 61131-2
IEC 61000-4-2
Electromagnetic
Radiated Emissions
80 ~ 1,000 MHz, 10 V/m
IEC 61131-2
IEC 61000-4-3
Electrical Fast
Transient & Burst
Immunity
Category Power module
Communication
Interface
IEC 61131-2
IEC 61000-4-4
Voltage 2.4 kV 1.2 kV
8 Environment Free from corrosive gases and excessive dust -
9
Operating height
Up to 2,000m(6,562ft)
-
10 Pollution degree 2 or less -
11
Cooling method
Natural Air-Cooling
-
