Chapter 5 Diagnostics
5-4
5.3 Backup Memory Diagnosis
If you press [Backup Memory] button, you can see the result of diagnosis in the result windows.
Remark
(1) If ‘NVRAM Data Access … Fail’ error is occurred, please contact with customer service center.
(2) If ‘BATTERY STATUS … BAD’ error is occurred, battery should be changed. Please contact with
Customer service center.
If the DIP switch No.1 is set up as B, please set it up as A. The ‘B’ is the mode in which the backup
battery is not used.
[Completion of Backup Memory diagnosis]
