Chapter 3 Standard Specification
3-4
Item
eXP40-TTE/DC
eXP40-TTA(B)/DC eXP60-TTA(B)/DC
Display type
TFT color LCD
Screen size
17.8cm(7”)
25.9 cm(10.2”)
Display Resolution 800 x 600 pixel(WVGA)
Color indication
24-bit Color(16.7M) 16-bit Color(65,536)
Indication degree
Left/Right:60 deg.
Upper:40 deg.
Lower:60 deg.
Left/Right:55 deg.
Upper:35 deg.
Lower:55 deg.
Backlight
LED Type (Supports backlight auto-off function)
Backlight duration
20,000 hours
Touch panel
4-Wire Resistive, analog
Audio Output Magnetic buzzer (85dB)
Process
i.MX283(454MHz)
Memory
Flash 128MB
Operating RAM
128MB
Backup RAM 128KB
Backup data Date/Hour data, Logging/Alarm/Recipe data and nonvolatile device
Battery duration Approx. 3 years (Operating ambient temperature of 50℃)
RTC Time error Approx. 3 sec/1day(Operating ambient temperature of 25℃)
Ethernet
-
1 channel, IEEE802.1a, 10Base-T/100Base-TX
USB Host 1 channel, USB 2.0 Host (mouse, keyboard, printer and USB memory driver is available)
USB Device
1 channel, USB 2.0 Device (for download and upload project file)
RS-485, RS-232C 2channels, RS-485, RS-232C (DSUB 9/Male Type)
RS-422/485
1channel, RS422/485 mode (Terminal Type)
Multi-language Up to 12 language simultaneously
Animation
GIF format is available
Recipe available
Data logging
available
Script executor available
Certifications
CE, UL(cUL), KC
Protection standard IP65
Dimension (mm) 208.0 x 154.0 x 44.4 276.0 x 218.0 x 44.4
Panel cut (mm) 192.0 x 138.0 260.0 x 202.0
Rated voltage
DC24V
Power consumption (W) 6.5W 10W
Weight(Kg)
0.62
0.63
1.08
