Specifications and Safety Warnings
Physical Specifications
Beta Draft Confidential
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/032-3
Physical Specifications
Table 2-2 describes the CBX 500 physical specifications.
Table 2-2. CBX 500 Physical Specifications
Specification Description
ATM Standards ATM Forum UNI (Version 3.0 and Version 3.1), ATM
Forum Interim Inter-Switch Signalling Protocol (IISP)
WAN Interfaces T1, E1, DS3(cell- and frame-based), E3 (cell-based),
OC-3c/STM-1 (optical and electrical), OC-12c/STM-4,
Ethernet
Management Interfaces Ethernet, RS-232
Physical Characteristics Basic switch includes three power supply modules, one
cooling fan module, one SP module, and one SPA module
mounted inside a chassis
Overall Switch Chassis Size
a
a
Depth size does not include calculations for cable spacing.
19.0 in. (48.26 cm) wide x 33.25 in. (84.455 cm) high x
15 in. (38.1 cm) deep
Switch Weight 200 lb max (fully configured)
