12
Using the Display, Softkeys and Display
Control Buttons
The following information will help you use the display, the softkeys, and the display
control buttons on your 8434DX voice terminal.
The softkeys are the five keys labeled with arrows ( ) located directly below the
display. The four display control buttons, labeled , ,
,
and
are located under the softkeys. Figure 3 shows the location of the
softkeys in relation to the display above the softkeys and the display control
buttons below them.
Figure 3. The Display, Softkeys, and Display Control Buttons
Menu Exit
Prev
Next
Softkeys
Display
control
Display
NextPrevMenu Exit
buttons
Entering Softkey Mode and Viewing the Three Feature Option Screens
There are three separate feature option screens. Each of these screens allows you to
select from five different features.
You can enter Softkey Mode by pressing the display option button labeled .
The following is an example of a feature option screen.
The top line of each feature option screen shows you the status of each of the five
features. An arrow appears above the name of a feature if that feature is active. If
there is no arrow above the feature, the feature is not active. In the above example,
the Automatic Callback feature is active because there is an arrow above that
feature name.
Note: If the feature requires you to dial a telephone number or extension, such as
Call Forwarding, you will temporarily see the digits you are dialing, rather than the
arrow, above the feature name.
The second line on each feature option screen shows the features you can access. To
use any of these features, you must press the softkey below the feature name. For
example, on the feature option screen shown on the previous page, you can leave a
message for another extension to call you back by pressing the softkey below LWC
Menu
LWC CnLWC Cnslt AutCB Timer
