MERLIN LEGENDCommunications System Release 6.1
System Planning
555-661-112
Issue 1
August 1998
Lines/Trunks
Page 3-10Identifying Line/Trunk Jacks
3
Function Information 3
If the system has a Voice Messaging System (such as Messaging 2000), you can
use the Function column to indicate which service is available for those jacks. You
can also use this column to indicate whether a jack connects a personal line and,
therefore, has an owner.
Planning Form Instructions 3
In the Function column of Form 2c, do
one
of the following:
■ If a jack is used for a special purpose, note the purpose. For example, if the
system has Messaging 2000 with fax capability, indicate the service by
writing one of the following for the appropriate jack:
— For Automated Attendant, write
AA.
— For Call Answer, write
CA.
— For Information Service, write
IS.
— For Message Drop, write
MD.
— For Voice Mail, write
VM.
— For Fax Response, write
FR.
■ If a jack is used for a personal line, write the extension number of the
telephone.
Proceed to the next section, “Selecting Line/Trunk Options.”
