Lucent Technologies MERLIN LEGEND Release 6.1 - Page 9

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
Issue 1
August 1998
Tables
Page ix
Tables 0
1 Before You Begin
1–1 Environmental Requirements 1–2
1–2 Control Unit Space Requirements 1–3
1–3 Employee Communications Survey: Description of
Questions 1–12
2 Control Unit Configuration
2–1 Application Ports 2–15
2–2 Modules with Touch-Tone Receivers 2–17
2–3 Touch-Tone Receivers Required by Voice
Messaging Systems 2–17
2–4 System Requirements for Touch-Tone Receivers 2–18
2–5 TTRs Required for Primary Delay Announcement Devices 2–19
2–6 TTRs Required for Secondary Delay Announcement
Devices 2–19
2–7 Maximum Number of Operator Positions 2–22
2–8 Application Ports 2–31
3 Lines/Trunks
3–1 Line/Trunk Jack Types 3–3
3–2 Codes for Line/Trunk Jacks 3–5
3–3 Line Compensation Settings 3–26
3–4 Line Compensation Settings 3–32
3–5 NI-1 BRI Timers 3–48
3–6 Total Number of TTRs Required 3–49
4 Features
4–1 Features That Can Be Copied 4–11
4–2 Disallowed List 7 Factory Set Entries 4–52
