Connect a Console
2-8 Communications Server Hardware Installation Guide
2. Ensure that DIP switch 1 is up.
3. Set the terminal to 9600 baud, 8 data bits, 1 stop bit, no parity, and software flow
control (XON/XOFF).
ETHERNET
ISDN/U ISDN/U ISDN/U ISDN/U ISDN/U ISDN/U
S0-S1 S2-S3 S4-S5 S6-S7 S8-S9 HD
C0 - DIAG
12345
1189-0018
