Cable and Ethernet Specifications B-15
High-Density 10-Pin Cable for the U Interface
High-Density 10-Pin Cable for the U Interface
Table B-11 gives pinout information for a 20-foot (6m), high-density 10-pin, unshielded,
24-gauge solid level 1 wiring cable with an RJ-45 connector and 10 loose wires.
Caution – Do not use the 10-pin RJ-45 cable in an 8-pin RJ-45 port. Incorrect cable
insertion can damage the PortMaster.
This cable is supplied with the MOD-10I-U expansion board and with models PM-2i-U
and PM-Ei-U. Additional cables can be ordered from Lucent. Specify product code
CBL-HD45. Punchdown blocks are available from electronic supply stores that carry
telephone equipment.
Disregard any solid red or solid blue lines because they are not used.
Ta b l e B - 11 High-Density 10-Pin Cable
Pin Color
Ports
S0-9
Ports
S10-19
Ports
S20-29
1 White-gray 5 S18-19 S28-29
2 White-brown 4 S16-17 S26-27
3 White-green 3 S14-15 S24-25
4 White-orange 2 S12-13 S22-23
5 White-blue 1 S10-11 S20-21
6 Blue-white 1 S10-11 S20-21
7 Orange-white 2 S12-13 S22-23
8 Green-white 3 S14-15 S24-25
9 Brown-white 4 S16-17 S26-27
10 Gray-white 5 S18-19 S28-29
!
