Size and Weight Specifications
C-2 Communications Server Hardware Installation Guide
* One RS-232/423 (console) port and three high-density 68-pin connectors, each supporting eight RS-232/423 asynchronous serial devices
Size and Weight Specifications
Table C-2 gives size and weight specifications.
Environmental and Electrical Specifications
Table C-3 gives environmental and electrical specifications.
ISDN S/T RJ-45 BRI with ISDN S/T
interface, providing two
64Kbps B channels and one
16Kbps D channel
-0, 5,
or 10
0, 5,
or 10
- - 5 5, 10, or
15
Ta b l e C - 2 Physical Specifications
Description PM-2, PM-2R, PM-25, PM-2i PM-2E, PM-2ER, PM-2Ei-10I
Dimensions
(HxWxD)
3.2 inches x 16.8 inches x 11.5 inches
(8.1cm x 42.7cm x 29.2cm)
6.5 inches x 16.8 inches x 11.5 inches
(16.5cm x 42.7cm x 29.2cm)
Weight 12.2lb. (5.5kg) 18.5lb. (8.4kg)
Ta b l e C - 3 Environmental and Electrical Specifications
Description Design Specifications
Operating temperature 41 to 113
o
F (5 to 45
o
C)
Storage temperature -40 to 185
o
F (-40 to 85
o
C)
Operating humidity 20 to 80%, noncondensing
Input Voltage 110VAC +/-10%, 47 to 63Hz, 1.0A
220VAC +/-10%, 47 to 63Hz, 0.6A
Power Dissipation 20W to 40W
Memory 512KB NVRAM,
4MB RAM expandable to 8MB or 16MB
Ta b l e C - 1 Interface Specifications (Continued)
Interface Description 2 2E 2ER 2R 25 2i 2E-I0I
