Ethernet Interface Specifications
B-16 Communications Server Hardware Installation Guide
Ethernet Interface Specifications
Table B-12 gives specifications for the 10Mbps baseband IEEE 802.3-compatible
Ethernet interface.
To obtain a product list and prices for optional Ethernet accessories available from
Lucent, contact the dealer from which you purchased your PortMaster.
Ta b l e B - 12 Ethernet Interface Specifications
Ethernet
Type
Connector
Type Cable Type
Transmission
Distance
10Base5
(AUI)
15-pin
DEC-Intel-Xerox
(DIX) for
connection to
external
transceiver
RG-11 50
ohm coaxial
Trunk segment—1,640ft (500m)
maximum Transceiver cable—164ft
(50m) maximum
Network trunk—8,200ft (2,500m)
maximum
10Base2
(BNC)
BNC
T-connector
RG-58 A/U
50 ohm
coaxial
Trunk segment—984ft (300m)
maximum
Station distance—1.5ft (0.5m)
maximum
Network trunk—3,035ft (925m)
maximum
10BaseT
(RJ-45)
RJ-45 for
10BaseT
Unshielded
twisted pair
Hub distance—328ft (100m)
maximum
Repeaters—four maximum
