High-Density 68-Pin Cable
B-6 Communications Server Hardware Installation Guide
DSR Data Set Ready 24 6 6
RXD Receive Data 58 6 3
DCD Data Carrier Detect 25 6 8
CTS Clear to Send 59 6 5
7 RTS Request to Send 26 7 4
DTR Data Terminal Ready 60 7 20
TXD Transmit Data 27 7 2
SGND Signal Ground 61 7 7
DSR Data Set Ready 28 7 6
RXD Receive Data 62 7 3
DCD Data Carrier Detect 29 7 8
CTS Clear to Send 63 7 5
8 RTS Request to Send 30 8 4
DTR Data Terminal Ready 64 8 20
TXD Transmit Data 31 8 2
SGND Signal Ground 65 8 7
DSR Data Set Ready 32 8 6
RXD Receive Data 66 8 3
DCD Data Carrier Detect 33 8 8
CTS Clear to Send 67 8 5
Ta b l e B - 3 High-Density 68-Pin-to-Eight DB-25 Cable–PM-25 only (Continued)
Port Signal Definition
68-Pin
Connector Pin
RS-232
Cable
DSub (male)
Pin
To Next Page
