Cable and Ethernet Specifications B-9
High-Density 50-Pin Cable
DSR Data Set Ready 24 2 36
RXD Receive Data 58 2 27
DCD Data Carrier Detect 25 2 21
CTS Clear to Send 59 2 29
7 RTS Request to Send 26 2 40
DTR Data Terminal Ready 60 2 42
TXD Transmit Data 27 2 38
SGND Signal Ground 61 2 44
DSR Data Set Ready 28 2 48
RXD Receive Data 62 2 39
DCD Data Carrier Detect 29 2 43
CTS Clear to Send 63 2 41
8 RTS Request to Send 30 2 15
DTR Data Terminal Ready 64 2 17
TXD Transmit Data 31 2 13
SGND Signal Ground 65 2 19
DSR Data Set Ready 32 2 23
RXD Receive Data 66 2 14
DCD Data Carrier Detect 33 2 18
CTS Clear to Send 67 2 16
Ta b le B - 4 High-Density 50-Pin Cable (Continued)
Quad Port Signal Definition
68-Pin
Number Connection Pin
To Next Page
