LK-T21 Technical Manual
GS a n
[Name] Enable/Disable Automatic Status Back (ASB)
[Format] ASCII GS a n
Hex 1D 61 n
Decimal 29 97 n
[Range] 0 ≤ n ≤ 255
[Description] Enables or disables ASB and specifies the status items to include, using n as follows:
Bit Off/ On Hex Decimal Status for ASB
Off 00 0 Drawer kick-out connector pin 3 status disabled.
0
On 01 1 Drawer kick-out connector pin 3 status enabled.
Off 00 0 On-line/off-line status disabled.
1
On 02 2 On-line/off-line status enabled
Off 00 0 Error status disabled
2
On 04 4 Error status enabled.
Off 00 0 Paper roll sensor status disabled.
3
On 08 8 Paper roll sensor status enabled.
4–7 - - - Undefined.
[Details] ·If any of the status items in the table above are enabled, the printer
transmits the status when this command is executed. The printer automatically transmits
the status whenever the enabled status item changes. The disabled status items may
change, in this case, because each status transmission represents the current status.
·If all status items are disabled, the ASB function is also disabled.
·If the ASB is enabled as a default, the printer transmits the status when the printer data
reception and transmission is possible at the first time from when the printer is turned on.
·The following four status bytes are transmitted without confirming whether the host is ready to
receive data. The four status bytes must be consecutive, except for the XOFF code.
·Since this command is executed after the data is processed in the receive
buffer, there may be a time lag between data reception and status transmission.
·When the printer is disabled by ESC = (Select peripheral device), the four status bytes are
transmitted whenever the status changes.
·When using DLE EOT, GS I , or GS r, the status transmitted by these
commands and ASB status must be differentiated.
·The status to be transmitted are as follows:
First byte (printer information)
Bit Off/On Hex Decimal Status for ASB
0 Off 00 0 Not used. Fixed to Off
1 Off 00 0 Not used. Fixed to Off
Off 00 0 Drawer kick-out connector pin 3 is LOW
2
On 04 4 Drawer kick-out connector pin 3 is HIGH
Off 00 0 On-line
3
On 08 8 Off-line
4 On 10 16 Not used. Fixed to On
Off 00 0 Cover is closed
5
On 20 32 Cover is open
Off 00 0 Paper is not being fed by using the PAPER FEED button
6
On 40 64 Paper is being fed by using the PAPER FEED button
7 Off 00 0 Not used. Fixed to Off
69
