LK-T21 Technical Manual
Drawer kick-out connector status ( n = 2, 50):
Bit Off / On Hex Decimal Function
Off 00 0 Drawer kick-out connector pin 3 is LOW.
0
On 01 1 Drawer kick-out connector pin 3 is HIGH.
1-3 - - - Undefined.
4 Off 00 0 Not used. Fixed to Off.
5,6 - - - Undefined.
7 Off 00 0 Not used. Fixed to Off.
[Reference] DLE EOT, GS a
GS v 0 m xL xH yL yH d1....dk
[Name] Print raster bit image
[Format] ASCII GS v 0 m xL xH yL yH d1...dk
Hex 1D 76 30 m xL xH yL yH d1...dk
Decimal 29 118 48 m xL xH yL yH d1...dk
[Range] 0 ≤ m ≤ 3, 48 ≤ m ≤ 51
0 ≤ xL ≤ 255
0 ≤ xH ≤ 255
0 ≤ yL ≤ 255
0 ≤ yH ≤ 8
0 ≤ d ≤ 255
k=(xL + xH x 256) x (yL + yH x 256) (k≠0)
[Description] Selects Raster bit-image mode.
The value of m selects the mode, as follows:
m Mode Vertical Dot Density Horizontal Dot Density
0, 48 Normal 180 dpi 180 dpi
1, 49 Double-width 180 dpi 90 dpi
2, 50 Double-height 90 dpi 180 dpi
3, 51 Quadruple 90 dpi 90 dpi
[dpi : dots per 25.4mm {1”}]
·xL, xH, select the number of data bytes (xL+xH×256) in the horizontal
direction for the bit image.
·yL, yH, select the number of data bytes (xL+xH×256) in the vertical
direction for the bit image.
[Details] ·In standard mode, this command is effective only when there is no data
in the print buffer.
·This command has no effect in all print modes (character size,
emphasized, double-strike, upside-down, underline, white/black
reverse printing, etc.) for raster bit image.
·If the printing area width set by GS L and GS W is less than the minimum
76
