Cura LulzBot Edition
Layers
To view the tool path of your print head and to ensure no skipped layers or
gaps use this option. Use the slide bar on the right hand side of the window
to move up and down through the tool path layers. Click the icon below
it to view an individual layer at a time. If the Print support structure
option is activated in Cura, it will be shown in blue.
Figure 2.9: View in Layers
Figure 2.10: Viewing Cumulative Layers
26
