Lumel RE72 User Manual

66
66
4028 O1TY
R 1…6
Output 1 type:
1 – relay output
2 – voltage output: 0/5 V
3 – current output : 4-20 mA
4 – current output : 0-20 mA
5 – voltage output: 0-5 V
6 – voltage output:: 0-10 V
RW
3…4
6)
4029 YFL RW 0…1000
Value of the control signal in case
when fa1l = Yfl
4030 OUT2 RW 0…17
Function of output 2:
0 – without function
1 – control signal - heating
or control signal „opening”
for analog valve
2 – control signal of stepper control
– opening
7)
3 – control signal of stepper control
– closing
7)
4 – control signal - cooling
or control signal „closing”
for analog valve
5 – absolute upper alarm
6 – absolute lower alarm
7 – relative upper alarm
8 – relative lower alarm
9 – relative internal alarm
10 – relative external alarm
11 – timer alarm
12 – alarm of heater burnout
13 – controlling element damage
alarm (short-circuit
14 – retransmission8)
15 – auxiliary output EV1 in the
programming control
16 – auxiliary output EV2 in the
programming control
17 – alarm in case of sensor failure
or exceeding the measuring
range
