List of confi guration parameters Table 1
6.4. Parameter Description
The list of parameters in the menu is presented in the table 1.
Parameter
symbol
Parameter
description
Manufac-
turer
setting
Range of parameter changes
sensors Linear input
inp – Input parameters
unit
Unit
qC
qC: Celsius degrees
qf: Fahrenheit degrees
pU: physical units
iNty
Kind of main
input
pt1
pt1: Pt100
pt10: Pt1000
t-,: thermocouple of J type
t-t: thermocouple of T type
t-k: thermocouple of K type
t-s: thermocouple of S type
t-r: thermocouple of R type
t-b: thermocouple of B type
t-e: thermocouple of E type
t-n: thermocouple of N type
t-l: thermocouple of L type
0-20: linear current 0-20mA
4-20: linear curren 4-20mA
0-5: linear voltage 0-5 V
0-10: linear voltage 0-10 V
dp
Position of the
main input
decimal point
1-dp
0_dp: without
decimal point
1_dp: 1 deci-
mal place
0_dp: without
decimal point
1_dp: 1 deci-
mal place
2_dp: 2 deci-
mal place
iNlo
Indication
for the lower
threshold of
the linear main
input
0.0 - -1999...9999 1)
