ACA
Range
Resolution
Accuracy
20A 0.001A,
< 10 A Meter + CP-1201 ±(1 %+0.1A)
0.01A,
≧
10 A Meter only ±(0.5 %+0.02A)
200A 0.01A,
< 100 A Meter + CP-1201 ±(1 %+0.5A)
0.1A,
≧ 100 A Meter only ±(0.5 %+0.2A)
1200A 0.1A,
< 1000 A Meter + CP-1201 ±(1 %+5A)
1A,
≧ 1000 A Meter only ±(0.5 %+2A)
Remark :
* When the Active power value ( P1 to P3 ) and Apparent
power value ( S1 to S3 ) show " - " indicator, it means the
current probe is under the reverse direction that compare
with the real measuring current.
Power factor
Range
Resolution
Accuracy
0.00 to 1.00 0.01 ±0.04
Remark :
* PFH : Long term power factor
* PFΣ:
For 3Φ4W, 3Φ3W, 1Φ3W : PFΣ = PΣ/SΣ
For 1Φ2W : PF1 = P1/S1
Φ ( Phase angle )
Range
Resolution
Accuracy
-180° to 180° 0.1° ±1°
* COS ( PF )
Frequency
Range
Resolution
Accuracy
45 to 65 Hz 0.1 Hz ±0.1 Hz
