Lutron Electronics DW-6195 - Page 11

Active (Real) Power
DW-6195 + CP1201
Range
Resolution
System
Accuracy
0.000 to 9.999 KW
*0.001/0.01/0.1 KW
±(1.2%+0.008KW)
10.00 to 99.99 KW
*0.01/0.1 KW
±(1.2%+0.08KW)
100.0 to 999.9 KW
0.1 KW
±(1.2%+0.8KW)
1.000 to 9.999 MW
0.001 MW
±(1.2%+0.008MW)
* The resolution is changed according the different ACA range.
Apparent Power
DW-6195 + CP1201
Range
Resolution
System
Accuracy
0.000 to 9.999 KVA
*0.001/0.01/0.1KVA
±(1.2%+0.008KVA)
10.00 to 99.99 KVA
*0.01/0.1 KVA
±(1.2%+0.08KVA)
100.0 to 999.9 KVA
0.1 KVA
±(1.2%+0.8KVA)
1.000 to 9.999 MVA
0.001 MVA
±(1.2%+0.008MVA)
* The resolution is changed according the different ACA range.
Reactive Power
DW-6195 + CP1201
Range
Resolution
System
Accuracy
0.000 to 9.999 KVAR
*0.001/0.01/0.1KVAR ±(1.2%+0.008 KVAR)
10.00 to 99.99 KVAR
*0.01/0.1 KVAR ±(1.2%+0.08 KVAR)
100.0 to 999.9 KVAR
0.1 KVAR ±(1.2%+0.8 KVAR)
1.000 to 9.999 MVAR
0.001 MVAR ±(1.2%+0.008 MVAR)
* The resolution is changed according the different ACA range.
Remark :
* When the Reactive power value ( Q1 to Q3 ) show " - "
indicator, it means the " current phase " lag than the " voltage
phase ", the load character is induction.
*
When the Reactive power value ( Q1 to Q3 ) do not show " - "
indicator, it means the " current phase " lead than the " voltage
phase ", the load character is capacitance.
