A : Folder Name range: WTA01 to WTA10.
B : Press ▲ or ▼ to select the expect folder number, the
number consists of " 01 to 10 " (as screen 1).
C : Press ▲ or ▼ continuously at least two seconds can
skip the numbers faster.
D : Press SHIFT KEY once, the symbol " SHIFT1" will
appear on up right display, and then press ▼ to entry next
setting function as screen 2 (Folder Name → File Name).
4-5-2 File Name: Set the file name for SD
A : The screen will show " NO File " indicator in REC Date
option when the selected file is new ( as screen 1 ).
B : The screen will show recording date and time in REC
Date option when the selected file has been recorded
as screen 2.
screen 1 ( 4-5-2 )
Folder Name: WTA03
SETUP
File Name:
3P401001.XLS
REC Date: NO File
Sampling Time: 2 Trans Ref : 220.0 V
Delet File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON
Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
19
To Next Page
