screen 2 ( 4-5-2 )
Folder Name: WTA03
3P401001.XLS
REC Date: NO File
Sampling Time: 2 Trans Ref : 220.0 V
Delet File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON
Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
C : File Name description : press ▲ or ▼ in screen 2 to
select expect file number from 001 to 050.
Remark : When press ▲ or ▼ > 2 sec, the setting
no. will change fast.
* 1P201001 : 1P2 means one phase by two wires.
* 1P301001: 1P3 means one phase by three wires,
* 3P301001 : 3P3 means three phases by three wires.
* 3P401001 : 3P4 means three phases by four wires.
* HAR01001 : HAR means harmonic measurement.
* PHA01001 : PHA means phasor measurement.
* TRA01001 : TRA means transient measurement.
Remark :
Above file description, 01 means folder number,
001 means file number.
D : The up right display will show " SHIFT1 " symbol
while pressing SHIFT KEY once in screen 2, and then
press ▼ to enter next setting function as screen 3
( File Name → Sampling Time ).
20
