E : The up right display will show " SHIFT2 " symbol
while pressing SHIFT KEY again in screen 4, at this time
press ▲ or ▼ to select 1P/2W(1P2)、1P/3W(1P3)、
3P/3W(3P3) and 3P/4W(3P4) as screen 4.
F: One by one to press SHIFT KEY to select different
functions circularly.
screen 3 (4-5-2)
Folder Name: WTA01
SETUP
File Name:
3P401001.XLS
SHIFT 1
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delet File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
screen 4 ( 4-5-2 )
Folder Name: WTA01
SETUP
File Name:
3P401001.XLS
SHIFT 2
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delet File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
