screen 2 ( 4-5-11 )
Folder Name: WTA01
SETUP
File Name: 3P401001.XLS
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delete File: 0 % SDVP : 10% 10%
SD Format: 0 %
Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
4-5-12 Clamp Type: set the clamp type to
Lutron Clamp or other Clamp
A : When press SHIFT KEY once the symbol " SHIFT1 " will
be disappeared and show as screen 2, at this time press
▲ or ▼ to select the Lutron standard clamp or other
Clamp ( CP-200, CP-1201, CP-2000. CP-2011, CP-3000,
CP-3001, CP-6001, Other ).
B : When select the different Clamp type, the V range
and the A range will show the corresponding value.
C : Press SHIFT KEY once again will return to screen 1 then
press ▼ to enter next setting function ( Clamp Type →
A range ).
35
To Next Page
