* Basic type :
The numerical data structure of SD card
is default used the " . " as the decimal,
for example "20.6" "1000.53" .
* Euro type :
The numerical data structure of SD card
is default used the " , " as the decimal,
for example "20,6" "1000,53" .
B : Press SHIFT KEY once again will return to screen 1 then
press ▼ to enter next setting function ( Decimal type →
Clamp type ).
screen 1 ( 4-5-11 )
Folder Name: WTA01
SETUP
File Name: 3P401001.XLS
SHIFT 1
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delete File: 0 % SDVP : 10% 10%
SD Format: 0 %
Decimal:
Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
