4-5-13 A range Setting ( Current range Setting )
A : When press SHIFT KEY once the symbol " SHIFT1 " will
be disappeared and show as screen 2, at this time press
▲ or ▼ to select A range to 20A to 2000A,
30A to 3000A or 60A to 6000A.
* The setting value should accoding your Clamp type.
* The CP-200 clamp can set 20A, 200A.
* The CP-1201 clamp can set 20A, 200A, 1200A.
* The CP-2000 clamp can set 20A, 200A, 2000A.
* The CP-2011 clamp can set 200A, 2000A.
* The CP-3000, CP-3001 clamp can set 30A, 300A, 3000A.
* The CP-6001 clamp can set 60A, 600A, 6000A.
* The Other clamp can set 20A, 200A, 2000A, 30A
300A, 3000A.60A, 600A, 6000A.
Attention :
The meter's A range ( Current range ) value should
same as the Clamp's current selecting range value.
B : Press SHIFT KEY once again will return to screen 1 then
press ▼ to enter next setting function ( A Range → V range ).
screen 1 ( 4-5-13 )
Folder Name: WTA01
SETUP
File Name: 3P401001.XLS
SHIFT 1
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delete File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB
A Range:
200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
37
