screen 2 ( 4-5-13 )
Folder Name: WTA01
SETUP
File Name: 3P401001.XLS
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delete File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB
A Range:
200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
4-5-14 V range Setting ( Voltage range Setting )
A : When press SHIFT KEY once the symbol " SHIFT1 " will
be disappeared and show as screen 2, at this time press
▲ or ▼ to select V range to 200mV, 300mV, 500mV,
1V, 2V, 3V.
* The setting function only available for the Other clamp.
* The V range value of CP-200, CP-1201 will default
to 200mV, it can not be adjusted.
* The V range value of CP-2000 will default to
2V, it can not be adjusted.
* The V range value of CP-2011, CP-3000, CP-3001,
CP-6001, will default to 3V, it can not be adjusted.
B : Press SHIFT KEY once again will return to screen 1 then
press ▼ to enter next setting function ( A Range →
RS232 OUT SEL ).
