screen 2 ( 4-5-16 )
Folder Name: WTA01
3P401001.XLS
REC Date: 2008-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delete File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Month Date Hour Minute Second
2010 11 13 14 37 25
4-5-17 When all settings are completed, press EXIT
KEY to return measuring screen.
4-5-18 The descriptions about SD CARD memory
space
A : Use Size - To show the space data numbers that have
been used.
B : Free Size - To show the data numbers of balance space.
C : Total Size - To show the data numbers of total space.
D : Typical SD CARD and SDHC both can be used with the
instrument, except the SD CARD memory size is less
than 32MB.
4-5-19 RESET KEY : Press this key to reboot the
instrument
45
