Measurement * V (phase-to-phase)
* V (phase-to-ground)
* A (phase-to-ground)
* KW / KVA / KVAR / PF (phase)
KW / KVA / KVAR / PF (system)
KWH / KVAH / KVARH / PFH (system)
* Power factor
* Phase angle
* Frequency
* Harmonics display.
Wire 1P/2W, 1P/3W, 3P/3W, 3P/4W.
connections
Voltage ranges 10 ACV to 600 ACV, auto range.
Current probe
* Current probe input signal volage ( ACV ) :
input signal
200mV/300mV/500mV/1V/2V/3V.
and range
* Current probe input current range ( ACA ) :
20 A/200A/2000A (1200 A)/30A/300A/3000A
60 A/600 A/6000 A.
* Meter can cooperate the universal current probe.
Safety IEC1010 CAT III 600 V.
standard
ACV input 10 Mega ohms.
impedance
Range select ACV Auto range.
ACA Manual range.
Clamp 40 Hz to 1 KHz.
frequency
response
Spec. tested 45 to 65 Hz.
frequency
Over load ACV 720 ACV rms
protection ACA 1300 ACA with clamp probe
* For the Clamp ,CP-1201
Over Indicator
* LCD display show " OL ".
* The data save into the SD card will show
" 9999 " or " 999 " ( overleap the decimal point ).
