26
ENGLISH
27. Power outlet
A 12-volt electric appliance may be connected to that jack connector. Electric
current is supplied when ever engine is running. See FUSES for electric power
outlet fuse location.
28. Fuse
To remove fuse from holder, pull fuse out. Check if filament is melted.
1. Fuse
2. Check if melted
Fuse for starting system and electric power outlet
Starting system and electric power outlet is protected (if equipped) with 20 ampe-
re fuse. If the starter and electric power outlet is out of function, check the fuse
condition and replace if needed.
NOTE:Do not use a higher rated fuse as this can cause severe damage to elec-
tric components and/or fire.
4-tec models and SDI: To open fuse box push on cover tab and tilt cover.
1. Push tab
