28
ENGLISH
30. Storage compartment
Depending on model, storage compartment situates either under the seat or
inside of the seat.
31. Rear rack
Some models:Always readjust suspension according to the load. The capacity
of this rack is limited. Ride at very low speed when loaded. Avoid speed over
bumps.
1. Open latch
32. Tool kit
A tool kit containing tools for basic maintenance is supplied with the engine. Tool
bag is located under the seat or hood.
33. Spark plug holder
Some models: To keep spare spark plugs dry and prevent shocks that might
affect the adjustment or break them, a holder is provided in engine compartment.
Firmly tighten them into the holder with spark plug socket (in tool kit) to ensure
that they will not be loosened by vibrations.
Spare spark plugs are not supplied with a new snowmobile.
Adjust spare spark plug gap according the TECHNICAL DATA before installation.
CAUTION: Do not attempt to adjust gap on spark plug BR9ECS; it is not adjus-
table.
