53
ENGLISH
Clean sheaves of both pulleys using BOMBARDIER Pulley flange cleaner (P/N
413 711 809).
Inspect the hood and repair any damage.
Touch up all metal spots where paint has been scratched off. Spray all metal parts
including shock chromed rods with BOMBARDIER LUBE (P/N 293 600 016).
Wax the hood and the painted portion of the frame fro better protection.
Apply wax on glossy finish only. Protect the vehicle with a cover to prevent dust
accumulation during storage.
The snowmobile has to be stored in a cold and dry place and covered with an
opaque tarpaulin. This will prevent sun rays from affecting vehicle finish.
Lift rear of vehicle until track is off the ground. Install on a mechanical stand.
Do not release track tension.
Drive belt removal and installation
1. Remove tether cord cap. Open engine compartment.
4-tec models only
1. Collar screw
2. Vent hose
3. Latch
1 Loosen collar screw on air silencer grommet.
2 Disconnect engine vent hose from air silencer.
1. Collar screw
2. Engine vent hose
3. Remove latch from air silencer.
