Too hard of adjustment
1. From the highest position, turn adjuster to select lowest position then, turn
adjuster to the desired position
2. Suspended Extension Adjustment
Suspended extension can be adjusted according to the load and snow condi-
tions.
For better deep snow performance or to increase reverse performance in deep
snow; first loosen lock nut then tighten nut 3/4 turn after contacting washers.
Retighten lock nut. Adjust the same on both sides.
For trail riding with a load or for pulling a load, first loosen lock nut. Turn to a
maximum preload of 3 turns after lock nut touching washers. Retighten lock nut.
Adjust the same on both sides.
3. Shackle Movement Limiter
Forest Fox : Install rubber bumper if you are mainly pulling a load. Rubber bumper
improves the handling when pulling a load.
For deep snow riding, do not install horse shoe washers.
For trail riding with passenger and/or weight; install 1 horse shoe washer under
each rubber stoppers.
For trail ride with heavy load and/or pulling a load ; install 2 horse shoe washers
under each rubber stoppers.
CAUTION:Always install same amount of washers on both sides.
