43
ENGLISH
Attach
the
other
end
of
emergency
rope
to the
starter
clip
supplied
in
the
tool
kit.
Hook
up
clip
on
drive
pulley
.
W
ind
the
rope
tightly
around
drive
pulley
.
When
pulled,
pulley
must
rotate
coun-
terclockwise.
1.
Knot
on
this
side
1.
Hook
up
starter
clip
1.
Clip
43
45
