56
ENGLISH
1. Tighten to open pulley
Turn sliding half clockwise then, pull on drive belt to open driven pulley. Follow
instruction on decals for belt removal and installation.
1. Turn sliding half clockwise
2. Pull belt to open driven pulley
Slip the belt over the top edge of the sliding half, as shown.
Installation
The maximum drive belt life span is obtained when the belt has the proper rotation
direction. Install it so the arrow printed on belt is pointing at front of vehicle.
1. Arrow pointing at front of vehicle
