35
Velocity
The Velocity settings determine the minimum (Min Vel) and maximum (Max Vel) velocities
each pad is capable of sending out.
To change a pad's minimum and maximum velocities:
1. Enter Pad Mode by pressing the Pad Mode Button (Pad).
2. Press the second Function Button (Edit Pads).
3. Use the Pad Bank button to select the desired pad bank, and press the pad whose
velocities you want to edit.
4. Turn the second Assignable Knob (Min Vel) to set the minimum velocity (00–127).
Turn the third Assignable Knob (Max Vel) to set the maximum velocity (00–127).
5. Make other changes in Pad Mode, or exit Pad Mode by pressing the Pad Mode Button
(Pad) or the fourth Function Button (Exit).
TRIGGER PADS 01: Preset
NOTE:
C1
MIN VEL:
00
MAX VEL:
127
PRESSURE:
Poly MORE EXIT
BANK:A PAD:A01
SELECT->
PAD
