PERFORMING PREDELIVERY CHECKS
5.2 Checking and Adding Wheel Drive Lubricant Level
1. Park the windrower on level ground.
2. Position windrower so plugs (A and B) are horizontally
aligned with the center (C) of the hub.
3. Stop the engine, and remove the key.
4. Remove plug (A or B). The lubricant should be visible
through the port or running o ut slightly.
5. If lubricant needs to be added, remove the second
plug (B), and add lubricant until lubricant runs out from
the other port (A). For lubricant specifications, refer to
6.4 Lubricants, Fluids, and System Capacities, page
374.
NOTE:
The type of lubrica nt used after the firs t lubricant
change is different from the factory supplied lubricant.
6. Reinstall plugs and tighten.
Figure 5.4: D rive Wheel Hub
147962 321 Revision A
