PERFORMING PREDELIVERY CHECKS
5.9 Checking Air Conditioning (A/C) Compressor B elts
1. Ensure A/C compressor belt (A) is tensioned so that a
force of 35–55 N (8–12 lbf) on belt deflects belt 5 mm
(3/16 in.) at mid-span.
Figure 5.18: A/C Compressor Belt
147962 331 Revision A
