REFERENCE
Table 6.11 O -Ring Boss (ORB) Hydraulic Fittings (Adjustable)
Torque Value
16
SAE Dash Size Thread Size (in.)
N·m
ft·lbf (*in·lbf)
-2 5/16–24 6–7 *53–62
-3 3/8–24 12–13 *106–115
-4 7/16–20 19–21 14–15
-5 1/2–20 21–33 15–24
-6 9/16–18 26–29 19–21
-8 3/4–16 46–50 34–37
-10 7/8–14 75–82 55–60
-12 1-1/16–12 120–132 88–97
-14 1-3/8–12 153–168 113–124
-16 1-5/1
6–12
176–1
93
130–1
42
-20 1-5/8–12 221–243 163–179
-24 1-7/8–12 270–298 199–220
-32 2-1
/2–12
332
–365
245
–269
16. Torque values shown are based on lubricated connections as in reassembly.
147962 365 Revision A
