UNLOADING AND ASSEMBLY
Form # 169080 Issue – April 2007
g. Remove bolt and washer securing pin to hitch.
CAUTION
Hold pin from falling to the ground when
bolt is removed.
h. Remove pin and reinsert pin in hitch from top.
i. Remove four bolts securing shipping bracket at
front of hitch, and remove bracket.
j. Remove banding from jack.
k. Remove pin (A) securing jack to hitch and
remove jack from shipping position.
l. Install at jack location at front of hitch and
secure with pin (A).
IMPORTANT
Ensure articulated hitch lock pin (B) is
installed and secured with lynch pin.
To Next Page
