Maeving | RM1S Owner’s Handbook
98
SPECIFICATIONS
Wheels and Tyres
Wheels Spoked wheels with aluminium rims
Front rim 2.15 x 19"
Rear rim 2.15 x 19"
Front tyre Dunlop K70 3.25 x 19 54P
Rear tyre Dunlop K70 3.25 x 19 54P
Front tyre pressure 2.2 Bar (32 PSI)
Rear tyre pressure 2.2 Bar (32 PSI)
Brakes
Front brake
Single disc brake 300 mm
(three piston floating caliper)
Rear brake
Single disc brake 180 mm
(single piston floating caliper)
Linked brakes Bias 40% front, 60% rear
Brake fluid DOT4
Height (excludes mirrors) 1067 mm
Width (includes mirrors) 896 mm
Weights
Unladen weight, road ready
(single battery)
141 kg
Permitted total weight 270 kg
Payload 129 kg
Service torques
Axle nuts on the front wheel axle Tighten to 65 Nm
Axle nuts on the rear wheel axle Tighten to 100 Nm
Securing bolts, front brake caliper
to suspension mounting
Tighten to 25 Nm
Securing bolts, rear brake caliper
to swinging arm
Tighten to 18 Nm
Rear mudguard stay fixings
Stay to swingarm - tighten to
10 Nm
Mudguard to stay – tighten to
8 Nm
Mudguard to swingarm –
tighten to 10 Nm
Dimensions
Seat height at vehicle curb weight 785 mm
Length
(includes number plate fitted)
2145 mm
