SPECIFICATIONS
SPECIFICATIONS
Motor
Type Bosch hub motor
Rated capacity 7.2 kW (9.7 hp)
Maximum power 11.1 kW (14.9 hp)
Maximum torque 260 Nm
Maximum speed 71.5mph (115 km/h)
Electrical system
Traction battery
Dual battery pack design
21700 Lithium-Ion LG M50-LT cells
in a bespoke aluminium casing
Battery voltage (nominal) 51.7 V
Charging capacity 52.8 Ah
Energy 2727.6 Wh
Charger 1200 W
Charging time
Approx. 6h for 0-100%
Approx. 4h for 0-80%
Approx. 2h:30mins for 20-80%
Input Universal 110 - 240 VAC
Secondary battery
12 V / 7 Ah, external 2-pin SAE
charge socket
Alternator
DC/DC converter with 500 W
integrated into battery control unit
Chassis
Frame CrMo Steel cradle frame
Front suspension/
suspension elements
Dia 37 non-adjustable forks,
110 mm travel
Rear wheel guide/
suspension elements
Twin RSU with pre-load adjustment,
110 mm travel
Wheelbase 1395 mm
Trail 103 mm
Rake angle 26°
