85
12-VOLT BATTERY
12-VOLT BATTERY
WARNING: Batteries are hazardous.
Before handling the batteries, make
sure you read and understand all
of the warnings given in Battery
handling safety on page 36.
Failure to comply with the warnings
increases the risk of injury, death, or
damage to the motorcycle or property.
WARNING: Batteries are dangerous
when mishandled or not used
correctly. Failure to adhere to the
following information could result in
damage to the motorcycle, damage to
the battery, injury or death.
Only install a 12-volt battery of the same type
and rating.
Make sure the ignition key is in the OFF
position before the 12-volt
battery is disconnected.
Always disconnect the negative terminal on
the 12-volt battery first and reconnect the
negative terminal last.
When removing and installing a 12-volt
battery, make sure that the battery terminals
do not come into contact with any metal
objects or vehicle components.
12-volt battery access panel
WARNING: Batteries are hazardous.
Before handling the batteries, make
sure you read and understand all
of the warnings given in Battery
handling safety on page 36.
Failure to comply with the warnings
increases the risk of injury, death, or
damage to the motorcycle or property.
Remove the primary and secondary batteries.
For further information, see Removing and
installing a battery on page 40.
To remove the battery access panel:
1. Make sure the ignition key is in the OFF
position.
2. Open the Maeving charging connector
cover.
3. Remove the 2 screws (T20 Torx™)
securing the Maeving badge to the hinge
and collect the washers (if fitted).
Note: When refitting, tighten to
3 Nm.
4. Return the hinge to the closed position.
2
3
