10 Programming Guide
Zone Definition Status
Zone Recognition
If a zone is already programmed and you assign a device to the same zone, a wireless zone will overwrite a keypad/hardwire zone, and a
keypad zone will overwrite a hardwire zone.
Zone Timers
Stay/ Sleep Alarm Delay -
Section [720] is 0
Stay/ Sleep Alarm Delay -
Section [720] is not 0
Zone
Definition
Description Stay Arm Sleep Arm Fully Arm Stay Arm Sleep Arm Fully Arm
01 Entry Delay 1 As is As is As is As is As is As is
02 Entry Delay 2 As is As is As is As is As is As is
03 Entry Delay1/Stay/Sleep Not Armed Not Armed Entry Delay 1 Not Armed Not Armed Entry Delay 1
04 Entry Delay1/Stay/Sleep Not Armed Not Armed Entry Delay 2 Not Armed Not Armed Entry Delay 2
05 Follow (Entry Delay/Instant) As is As is As is Follow (Entry
Delay/SleepDelay)
Follow (Entry
Delay/SleepDelay)
Follow (Entry
Delay/Instant)
06 Follow/Stay Not Armed Follow (Entry
Delay/Instant)
Follow (Entry
Delay/Instant)
Not Armed Follow (Entry
Delay/SleepDelay)
Follow (Entry
Delay/Instant)
07 Follow/Stay/Sleep Not Armed Not Armed Follow (Entry
Delay/Instant)
Not Armed Not Armed Follow (Entry
Delay/Instant)
08 Instant As is As is As is Sleep Delay Sleep Delay Instant
09 Instant/Stay Not Armed Instant Instant Not Armed Sleep Delay Instant
10 Instant/Stay/Sleep Not Armed Not Armed Instant Not Armed Not Armed Instant
11 Instant Fire As is As is As is As is As is As is
12 Delayed Fire As is As is As is As is As is As is
13 Instant Fire Silent As is As is As is As is As is As is
14 Delayed Fire Silent As is As is As is As is As is As is
15 24HR Buzzer As is As is As is As is As is As is
16 24HR Burglary As is As is As is As is As is As is
17 24HR Hold-up As is As is As is As is As is As is
18 24HR Gas As is As is As is As is As is As is
19 24HR Heat As is As is As is As is As is As is
20 24HR Water As is As is As is As is As is As is
21 24HR Freeze As is As is As is As is As is As is
Wireless:
Overwrites a keypad or hardwire zone assigned to
same zone.
Keypad:
Overwrites a hardwire zone assigned to same
zone.
Hardwire Panel Input
Zone 1 Yes Yes Yes (Panel Input 1)
Zone 2 Yes Yes Yes (Panel Input 2)
Zone 3 Yes Yes Yes (Panel Input 1with ATZ)
Zone 4 Yes Yes Yes (Panel Input 2 with ATZ)
Zone 5 to 32 Yes Yes No
Section Data Description
[041] = Zone 1: ____/____/____ (000 to 255) x 10ms Hardwire Zone 1 Speed (Default 060)
[042] = Zone 2: ____/____/____ (000 to 255) x 10ms Hardwire Zone 2 Speed (Default 060)
[043] = Zone 3: ____/____/____ (000 to 255) x 10ms Hardwire Zone 3 Speed (Default 060)
[044] = Zone 4: ____/____/____ (000 to 255) x 10ms Hardwire Zone 4 Speed (Default 060)
