Magellan 19
Wireless Output Serial Number
To delete a wireless PGM, enter [000000] in its respective section.
To view the serial number display, refer to section [960].
Wireless PGM Signal Strength
PGM Recognition
A Wireless PGM module can be assigned to any PGM. It will overwrite the Control Panel Output.
Section Wireless PGM Serial Number Section Wireless PGM Serial Number
[301]= PGM 1: ____/____/____/____/____/____ [309]= PGM 9: ____/____/____/____/____/____
[302]= PGM 2: ____/____/____/____/____/____ [310]= PGM 10: ____/____/____/____/____/____
[303]= PGM 3: ____/____/____/____/____/____ [311]= PGM 11: ____/____/____/____/____/____
[304]= PGM 4: ____/____/____/____/____/____ [312]= PGM 12: ____/____/____/____/____/____
[305]= PGM 5: ____/____/____/____/____/____ [313]= PGM 13: ____/____/____/____/____/____
[306]= PGM 6: ____/____/____/____/____/____ [314]= PGM 14: ____/____/____/____/____/____
[307]= PGM 7: ____/____/____/____/____/____ [315]= PGM 15: ____/____/____/____/____/____
[308]= PGM 8: ____/____/____/____/____/____ [316]= PGM 16: ____/____/____/____/____/____
Section Section
[321] PGM 1 Wireless PGM Signal Strength [329] PGM 9 Wireless PGM Signal Strength
[322] PGM 2 Wireless PGM Signal Strength [330] PGM 10 Wireless PGM Signal Strength
[323] PGM 3 Wireless PGM Signal Strength [331] PGM 11 Wireless PGM Signal Strength
[324] PGM 4 Wireless PGM Signal Strength [332] PGM 12 Wireless PGM Signal Strength
[325] PGM 5 Wireless PGM Signal Strength [333] PGM 13 Wireless PGM Signal Strength
[326] PGM 6 Wireless PGM Signal Strength [334] PGM 14 Wireless PGM Signal Strength
[327] PGM 7 Wireless PGM Signal Strength [335] PGM 15 Wireless PGM Signal Strength
[328] PGM 8 Wireless PGM Signal Strength [336] PGM 16 Wireless PGM Signal Strength
RSSI - Receiver Signal Strength Indicator (1 = weak signal, 10 = strong signal)
Signal Strength Keypad Audible Indicator
1 to 4 (relocate wireless PGM) 1 beep
5 to 7 2 beeps
8 to 10 3 beeps
Wireless Hardwire
PGM 1 Yes Yes
PGM 2 Yes Yes
PGM 3 to 16 Yes No
