Magellan 25
System Timers
[705] General Zone Options 1
Option OFF ON
[1]
ATZ zone doubling
N Disabled N Enabled
[2]
ATZ wiring options
N Series N Parallel
[3] & [4]
[5]
Generate tamper on bypassed zone
N No N Yes
[6] & [7]
[8]
Generate supervision on bypassed zone
N No N Yes
[706] General Zone Options 2 Bold = Default setting
Option OFF ON
[1]
Check-in supervision time
N 24 hours N 80 minutes
[2]
EOL resistors
N Disabled N Enabled
[3]
Zone Input 1 becomes a 2-wire smoke input
N Disabled N Enabled
[4] to [6] Future use N/A N/A
[7] & [8] N/A N/A N/A
Section Data Description
[710] ____/____/____ (000 to 255) seconds Entry delay 1 (default 045)
[711] ____/____/____ (000 to 255) seconds Entry delay 2 (default 045)
[712] ____/____/____ (000 to 255) max 15 Auto zone shutdown counter (Default 005)
[713] ____/____/____ (000 to 255) seconds Intellizone delay (default 048)
[714] ____/____/____ (000 to 255) minutes Recycle alarm delay (default 000)
[715] ____/____/____ (000 to 255) Recycle alarm counter (default 000)
[716] ____/____/____ (000 to 255) minutes Keypad lockout delay (default 000)
[717] ____/____/____ (000 to 255) attempt before locking Keypad lockout counter (default 000)
[718] ____/____/____ (000 to 255) seconds Remote panic disarm lock delay (default 000)
[719] ____/____/____ (000 to 255) days Closing delinquency delay (default 000)
[720] ____/____/____ (000 to 255) seconds Sleep Arm Alarm Delay (default 015)
[3] [4]
RF Zone Tamper Recognition Options Keypad / Bus Module Tamper Recognition Options*
OFF OFF Disabled TROUBLE ONLY
OFF ON TROUBLE ONLY TROUBLE ONLY
ON OFF When disarmed: TROUBLE ONLY
When armed: Follow zone’s alarm type
TROUBLE ONLY
ON ON When disarmed: AUDIBLE ALARM
When armed: Follow zone’s alarm type
AUDIBLE ALARM
* Tamper recognition of keypad / bus module only if section [700] option [7] is enabled.
[6] [7]
RF Zone Supervision Options Keypad / Bus Module Supervision Options
OFF OFF Disabled Disabled
OFF ON TROUBLE ONLY TROUBLE ONLY
ON OFF When disarmed: TROUBLE ONLY
When armed: Follow zone’s alarm type
TROUBLE ONLY
ON ON When disarmed: AUDIBLE ALARM
When armed: Follow zone’s alarm type
AUDIBLE ALARM
