Page #17 background image
Magellan 17
Programmable Output Options
49 = Low battery on zone 01 to 32 = Zone number
99 = Any zone number
50 = Low battery on zone restore 01 to 32 = Zone number
99 = Any zone number
51 = Zone supervision trouble 01 to 32 = Zone number
99 = Any zone number
52 = Zone supervision restore 01 to 32 = Zone number
99 = Any zone number
53 = Wireless output supervision trouble 01 to 16 =Output number
99 = Any output number
54 = Wireless output supervision restore 01 to 16 =Output number
99 = Any output number
55 = Wireless output tamper trouble 01 to 16 =Output number
99 = Any output number
56 = Wireless output tamper trouble restore 01 to 16 =Output number
99 = Any output number
57 = Non-medical alarm (paramedic) 01 to 32 = User number
99 = Any user number
58 = Zone forced 01 to 32 = Zone number
99 = Any zone number
59 = Zone included 01 to 32 = Zone number
99 = Any zone number
Default:
Bold
Section:
PGM 1
[261]
PGM 2
[262]
PGM 3
[263]
PGM 4
[264]
Option OFF ON OFF ON
OFF ON OFF ON
[1] PGM Base Time (Off=Sec; On=Min)
N N N N
[2] PGM State (Off=N.O., On=N.C.)
N N N N
[3] PGM Supervision
N N N N
[4] PGM Activation Mode (Off=Steady, On=Pulse)
N N N N
[5] PGM Pulse once every 30 seconds if armed
N N N N
[6] to [8] Future Use N/A N/A N/A N/A N/A N/A N/A N/A
Default:
Bold
Section:
PGM 5
[265]
PGM 6
[266]
PGM 7
[267]
PGM 8
[268]
Option OFF ON
OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec.; On=Min.)
N N N N
[2] PGM State (Off=N.O., On= N.C.)
N N N N
[3] PGM Supervision
N N N N
[4] PGM Activation Mode (Off=Steady, ON=Pulse)
N N N N
[5] PGM Pulse once every 30 seconds if armed
N N N N
[6] to [8] Future Use N/A N/A N/A N/A N/A N/A N/A N/A
Event Group # Sub-group #
