Page #18 background imageLoading...
Page #18 background image
18 Programming Guide
Programmable Output Delays
Default:
Bold
Section:
PGM 9
[269]
PGM 10
[270]
PGM 11
[271]
PGM 12
[272]
Option OFF ON
OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec; On=Min)
N N N N
[2] PGM State (Off=N.O., On=N.C.)
N N N N
[3] PGM Supervision
N N N N
[4] PGM Activation Mode (Off=Steady, On=Pulse)
N N N N
[5] PGM Pulse once every 30 seconds if armed
N N N N
[6] to [8] Future Use N/A N/A N/A N/A N/A N/A N/A N/A
Default:
Bold
Section:
PGM 13
[273]
PGM 14
[274]
PGM 15
[275]
PGM 16
[276]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec; On=Min)
N N N N
[2] PGM State (Off=N.O., On=N.C.)
N N N N
[3] PGM Supervision
N N N N
[4] PGM Activation Mode (Off=Steady, On=Pulse)
N N N N
[5] PGM Pulse once every 30 seconds if armed
N N N N
[6] to [8] Future Use N/A N/A N/A N/A N/A N/A N/A N/A
Section Data Description
[281]= PGM 1: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 1 Delay (Default 005)
[282]= PGM 2: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 2 Delay (Default 005)
[283]= PGM 3: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 3 Delay (Default 005)
[284]= PGM 4: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 4 Delay (Default 005)
[285]= PGM 5: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 5 Delay (Default 005)
[286]= PGM 6: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 6 Delay (Default 005)
[287]= PGM 7: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 7 Delay (Default 005)
[288]= PGM 8: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 8 Delay (Default 005)
[289]= PGM 9: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 9 Delay (Default 005)
[290]= PGM 10: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 10 Delay (Default 005)
[291]= PGM 11: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 11 Delay (Default 005)
[292]= PGM 12: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 12 Delay (Default 005)
[293]= PGM 13: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 13 Delay (Default 005)
[294]= PGM 14: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 14 Delay (Default 005)
[295]= PGM 15: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 15 Delay (Default 005)
[296]= PGM 16: ___/___/___ ( 000 to 255 x 1 sec./mins.) PGM 16 Delay (Default 005)
