Form 07A –Frontier V6, V4 and Extreme X8 Owner’s Manual ENGLISH.docx Revision No.4
© Magic Mobility Page 19 of 65
Motors engaged; Drive (levers up)
Motors disengaged; Freewheel (levers down)
Figure 10 - Extreme X8 Drive and Freewheel Mode
Motors engaged; Drive (levers up)
Motors disengaged; Freewheel (levers down)
Figure 11 - Frontier V4 FWD and Frontier V4 RWD Drive and Freewheel Mode
The wheelchair controls will not function and a message will appear on the screen “brake error”
when the chair is in free-wheel mode. This feature has been intentionally incorporated to protect the
user from unsafe situations. These levers are intended for use by the attendant.
Push the levers back up again firmly after manually positioning the chair. Turn the power off and on
again to remove the error message.
WARNING! Do not use your chair in freewheel mode or attempt to place your chair
into freewheel mode without an attendant present. You may cause injury to yourself
and to others. Do not place your power chair in freewheel mode while on an incline.
The chair could roll uncontrollably on its own, leading to injury to yourself and
others.
WARNING! THERE IS NO BRAKING ON THIS WHEELCHAIR WHEN IT IS IN FREEWHEEL MODE.
5.4 Electrical Safety Protection
Your wheelchair has a fuse fitted into the battery circuit to protect the motors and electronics from
an accidental current overload. In the case of a blown fuse, the chair will not drive and you will need
to contact your Magic Mobility dealer for repair / replacement
